Осциллограф Tektronix, TBS1064
Bandwidth 60MHz
Calibrated RSCAL
Dimensions 124.2 x 326.3 x 158mm
Display Type TFT LCD
Height 158mm
Length 124.2mm
Maximum Operating Temperature +50°C
Maximum Time Base 50s/div
Maximum Vertical Sensitivity 5V/div
Minimum Operating Temperature 0°C
Minimum Time Base 5ns
Minimum Vertical Sensitivity 2mV
Model Number p TBS1064
Number of Channels 4
Oscilloscope Type Digital Storage
Power Source Mains
Record Length 2.5k points/ch
Safety Category CAT II 300 V
Safety Category Level CAT II
Safety Category Voltage 300V
Sample Rate Random 1 Gsps
Screen Size 5.7in
Series TBS1000
USB Interface Yes
Vertical Resolution 8 bit
Weight 2kg
Width 326.3mm

Информация

Производитель: Tektronix

Артикул производителя: TBS1064
