Осциллограф LeCroy, WaveAce 2022
Bandwidth 200MHz
Dimensions 360 x 124.1 x 163mm
Display Type Colour
Height 163mm
Length 360mm
Maximum Operating Temperature +40°C
Maximum Time Base 50s/div
Maximum Vertical Sensitivity 5V/div
Minimum Operating Temperature +10°C
Minimum Time Base 2.5ns/div
Minimum Vertical Sensitivity 2mV/div
Model Number p WaveAce 2022
Number of Channels 2
Oscilloscope Type Bench
Power Source Mains
Record Length 12k points/ch
Rise Time 1.75ns
Safety Category CAT I 400 V
Safety Category Level CAT I
Safety Category Voltage 400V
Sample Rate Random 1 Gsps
Screen Size 7in
Series WaveAce 2000
USB Interface Yes
Vertical Resolution 8 bit
Weight 3.33kg
Width 124.1mm

Информация

Производитель: LeCroy

Артикул производителя: WaveAce 2022
