Number Of Pairs 3
Core Colours Black and Red (Number 1); Black and White (Number 2); Black and Green (Number 3)
Shielded Yes
Outer Sheath Material PVC or LSNH
Cable O/D (mm) 8.5
Outer Sheath Properties Halogen Free; Low Smoke; Flame Resistant; Non Corrosive
Shielding Material Beldfoil Aluminium-Polyester
Conductor Insulation Material Datalene
Conductor Material Tinned Copper
CSA 0.23mm²
Drain Wire Yes
Impedance 100Ω
Individual Shield Yes
Number Of Conductor Strands 7
Reel Length (m) 152 m
Sheath Colour Grey
Size Of Conductor Strands 32 awgawg
Velocity Of Propagation % 78
Voltage Rating 30V
Информация
Производитель: Belden
Артикул производителя: 9730.00153
