Реле OMRON, G6M-1A 5DC
Contact Configuration SPST-NO
Coil Voltage 5Vdc
Current Rating Max. 5 A
Maximum Voltage Rating 270 Vac; 125 Vdc
Power Rating Max. 90W / 750VA
Coil Resistance info 208 Ω
Coil Power info 120 mW
Contact Resistance 100mΩ
Life 20,000,000
Operating Temperature -40 → +85°C
Mounting Through Hole
Relay Construction Non-Latching
Isolation Coil To Contact 3000V
G6M Series

Slim, miniature relay capable of relaying Programmable Controller Outputs

* 5mm width
Reduced mounting area ideal for high density mounting
Highly efficient magnetic circuit for high sensitivity
SIL (Single-In-Line) terminal pitch
SPST-NO contacts
Expected life cycle 2 x 107
Operating temperature range - 40 to +85°C

Информация

Производитель: Omron

Артикул производителя: G6M-1A 5DC
