Реле OMRON, G5V-1 5DC
Contact Configuration SPDT
Coil Voltage 5Vdc
Current Rating Max. 1 A
Maximum Voltage Rating 125 Vac; 60 Vdc
Power Rating Max. 30W / 62.5VA
Coil Resistance info 166.7 Ω
Coil Power info 150 mW
Contact Resistance 100mΩ
Contact Material Ag + Au Clad
Life 5 x 106
Operating Temperature -30 → +70°C
Mounting Through Hole
Relay Construction Non-Latching
Isolation Coil To Contact 1000V
G5V-1 Series

* Fully sealed
High sensitivity: 150mW nominal coil power
Contact material. Ag + Au Clad
Contact configuration: SPCO
Expected life cycle 5 x 106
Operating temperature range - 30 to +70°C
Available single or in tubes of 25

Approvals
UL, CSA conforms to FCC part 68

Информация

Производитель: Omron

Артикул производителя: G5V-1 5DC
