Tripping Characteristics Type B
Current Rating 63A
Type B Two Poles 10kA

Type B characteristic offers instantaneous short circuit response level of 3-5 x normal rated current, making it suitable for circuits with moderate inrush currents such as filament lamps, heating loads and most domestic/small building protection applications.

* DIN rail mounting
Complies with BS EN 60898
Operating temperature range of -25°C to +55°C
Standard 35mm width
Max. operating voltage 440Vac

Информация

Производитель: ABB

Артикул производителя: 2CDS272001R0635
