Зарядное устройство Elektro-Automatik, EA-PS 548-05 R
EA-PS 500 series
High performance despite very compact housing
Cycled switch controller with PFC
Table-top devices (... T) with 4 mm sockets
Wall-mounted devices (... R) with screw clamps
Output voltage adjustable up to +20 / -10% with one screwdriver
Remote detection (sense)
Dimensions (W x H x D): 110 x 58 x 226 mm
Model
EA-PS Voltage
(V) Current
(A) Output
(W) Efficiency
type (%) Weight
(kg)
512-11 R/T 11 → 14 10.5 150 75 1.65
512-21 R/T 11 → 14 21 300 75 1.75
524-05 R/T 22 to 29 5.2 150 78 1.65
524-11 R/T 22 to 29 10.5 300 78 1.75
548-05 R/T 43 → 58 5.2 300 78 1.75
Standards
EN 60950, EN55014 parts 1 & 2
Elektro-Automatik

Информация

Производитель: Elektro-Automatik

Артикул производителя: EA-PS 548-05 R
