Реле MEDER, H12-1A69
Contact Configuration SPST-NO
Coil Voltage 12Vdc
Switching Current 3A
Switching Voltage 10 kVdc or ac peak
Switching Power 50W
Coil Resistance 340Ω
Coil Power 420mW
Contact Resistance 150 (max)mΩ
Contact Material Wo
Operation Time - Including Bounce 3ms
Release Time 0.5ms
Isolation Coil To Contact 15kVac
SPNO H Series

* Coil covered with a thermoplastic casing according to UL 94V-0
M4 screw fastening option
High insulation resistance
Maximum continuous current: 5A
Vibration resistance: 20g at 50 - 500 Hz
Operating temperature: -20°C to +70°C
Maximum switching current: 3A
Maximum switching power: 50W

Информация

Производитель: Meder

Артикул производителя: H12-1A69
