Реле OMRON, G6L-1P 24DC
Contact Configuration SPST-NO
Coil Voltage 24Vdc
Current Rating Max. 1 A
Maximum Voltage Rating 125 Vac; 60 Vdc
Coil Resistance info 2504 Ω
Coil Power info 230 mW
Contact Resistance 100mΩ
Life 5 x 106
Operating Temperature -40 → +70°C
Mounting Through Hole
Relay Construction Non-Latching
Isolation Coil To Contact 1000Vac
G6L-1P Series

Extremely thin SPST-NO flat relay

* Dimensions: 7x10.6x4.2 (WxLxH) SMD or 3.8mm (H) TH version
Dielectric strength between coil and contacts 1000 Vac, 50//60 Hz for 1min.
Conforms to FCC part 68
Use of lead completely eliminated
Max. Switching current 1A
Max. Switching voltage 125Vac 60Vdc
Expected life cycle 5 x 106
Operating temperature range -40 to +70°C

Информация

Производитель: Omron

Артикул производителя: G6L-1P 24DC
