Body Orientation Right Angle
CAD Drawing 3D CAD Model
Contact Material Copper Alloy
Contact Plating Gold over Nickel
Current Rating 3A
Depth 8.92mm
Dimensions 36.45 x 12.45 x 8.92mm
Gender Male
Housing Material Liquid Crystal Polymer
Length 36.45mm
Maximum Operating Temperature +150°C
Minimum Operating Temperature -55°C
Mounting Type Through Hole
Number of Contacts 51
Pitch 1.91mm
Series GMR7590
Width 12.45mm

Информация

Производитель: Glenair

Артикул производителя: GMR7590-51P-1BPN
